MS Paint: Vintage Apparatus
#1
Plaistow NH, Engine 1 - 1926 Seagrave



Plaistow still has this truck and it is kept behind there currnet station in a garage that houses a 1948 Diamod T that replaced the Seagrave and is assigned as Engine 1 as well.




Reply
#2
An FDNY Relay Hose Wagon. FDNY utilized these during the WWII era in the event of water main damage during a major air attack on the city. Each of the five carried 3,000 feet of hose. They were converted ALF tillered aerials and were painted grey to make them less of a target for enemy planes. Credit to EMTChris67, Mayer22,and Fyreline.


Attached Files Thumbnail(s)

Reply
#3
Two more FDNY rigs, both on GMC chassis. A brush patrol and foam supply unit. Credits to EMTChris67, Mayer22, Ladder13, and Engine5161


Attached Files Image(s)

Reply
#4
An FDNY field canteen unit. Credits to Fyreline, Ladder13, and Mayer22.


Attached Files Image(s)

Reply
#5
FDNY Rescue 1. From my original drawing to MS Paint.


Attached Files Image(s)

Reply
#6


Started working on some 1950's USAF Fire & Crash Rescue Trucks. Up first is an O-11A. This is a 1954 model from American LaFrance.
Reply
#7


Next former USAF Crash Rig is the O-6 CO2 truck.
Reply
#8


My next Crash Truck is a 1957 American LaFrance O-11B
Reply
#9


The 4th installment of a 1950's USAF Unit is this 750A Structual Pumper.
Reply
#10
To round out the USAF 1950's apparatus was the small but powerful - R-2. Based on a Dodge M35 Chassis, this would be the USAF Rescue Truck at every base until the 1970's.
Reply
#11
Interesting to see some of the older and different pieces of equipment.

Good drawings!



tHANKs
tHANKs
Reply
#12
Amazing as always. It's nice to see the older trucks shown in MS Paint.
Reply
#13
Reply
#14
1941 American LaFrance with "canoe" & A 1944 American LaFrance 500 series without the "canoe"


Attached Files Image(s)

Reply
#15
JERSEY CITY NJ ENGINE 1


Attached Files Image(s)

Reply
#16
[quote name='FDJCengine2' timestamp='1304209714' post='437515']

JERSEY CITY NJ ENGINE 1

[/quote]


Attached Files Thumbnail(s)

Reply
#17
American la France


Attached Files Thumbnail(s)

Reply
#18
FDNY Mobile Medical Station. A 1983 ALF/Saulsbury. Credits in the drawing.


Attached Files Image(s)

Reply
#19
Mack Bulldog rescue for FDNY's Rescue 2. Credits posted in the drawing.


Attached Files Image(s)

Reply
#20
Mid 80's American laFrance Engine.CREDIT to Guest_Rescue29Engine23


Attached Files Image(s)

Reply
